Canarm brand Model DDA Industrial Grade Direct Drive Tube Axial Duct Fan for Clean Dry Air

Cut Sheet & Performance Chart (614 Kb)

Operation & Maintenance Manual (494 Kb)

Options:

Price: $1,033.32

Got Questions or Need a Quote? We're Ready to Help!

Description
Reviews

DDA - DIRECT DRIVE TUBE AXIAL DUCT FANS

Minimum maintenance. Maximum efficiency.

FEATURES

Cast aluminum blades are standard.

TEFC motors are standard.

For clean, dry air with a maximum temperature of 100ºF (40ºC)

		MODEL#		H.P.	CFM @ Static Pressure
		115/230V/1 Phase/60 Hz	2230-460V/3 Phase/60 Hz		CFM @ Static Pressure
		115/230V/1 Phase/60 Hz	2230-460V/3 Phase/60 Hz		0”	.25”	.50”	.75”	1”	1.25”
Size	12"	DDA12T10033B	DDA12T30033BM	1/3	1450	1230	313	--	--	--
	12"	DDA12T100200A	DDA12T30200AM	2.0	2860	2740	2640	2530	2410	2140
	14"	DDA14T10033C	DDA12T30033CM	1/3	1450	443	--	--	--	--
	14"	DDA14T10033B	DDA14T30033BM	1/3	2220	1920	1350	512	185	--
	15"	DDA15T10033B	DDA15T30033BM	1/3	2630	2320	1840	--	--	--
	16”	DDA16T10033C	DDA16T30033CM	1/3	2150	1640	340	--	--	--
	16”	DDA16T10050B	DDA16T30050BM	1/2	3300	3040	2690	1750	825	370
	18”	DDA18T10033C	DDA18T30033CM	1/3	2990	2450	845	--	--	--
	18”	DDA18T10075B	DDA18T30075BM	3/4	4590	4280	3910	3260	1750	--
	20"	DDA20T10033C	DDA20T30033CM	1/3	4530	3180	739	--	--	--
		DDA20T10100B	DDA20T30100BM	1.0	6950	6155	5300	3225	1860	853
		DDA20T10200B	DDA20T30200BM	2.0	7893	7486	6506	5336	4060	2513
	24"	DDA24T10050C	DDA24T30050CM	1/2	4990	4180	2920	1210	--	--
		DDA24T10100C	DDA24T30100CM	1.0	6520	5630	4380	1920	813	--
		DDA24T10150C	DDA24T30150CM	1.5	8710	7630	6020	2380	720	--
		DDA24T10150B	DDA24T30150BM	1.5	7660	7160	6620	5980	5170	4020
		DDA24T10200B	DDA24T30200BM	2.0	9210	8660	8090	7470	6660	5540
		DDA24T10300B	DDA24T30300BM	3.0	11500	10900	10200	9490	8680	7540
	30"	DDA30T10100C	DDA30T30100CM	1.0	8680	7480	6000	3630	1550	--
		DDA30T10150C	DDA30T30150CM	1.5	11800	10600	8950	6070	3070	--
		--	DDA30T30200CM	2.0	12780	11490	9850	7320	3620	--
		--	DDA30T0300CM	3.0	16400	14700	12700	6840	4120	--
		DDA30T10300B	DDA30T30300BM	3.0	13300	12550	11700	11000	9980	8830
		DDA30T10500B	DDA30T30500BM	5.0	18200	17350	16550	15200	14600	13880
		DDA30T10750B	DDA30T30750BM	7.5	22600	21980	20650	19030	18300	17550
	34"	--	DDA34T30200CM	2.0	15300	13800	12000	10490	6070	3440
		--	DDA24T30300CM	3.0	19300	17700	15600	12900	8620	6110
		--	DDA24T30500CM	5.0	22500	20550	18300	13100	10200	6860
		DDA24T10500B	DDA24T30500BM	5.0	18700	17820	16800	15700	14600	13660
		DDA24T10750B	DDA24T30750BM	7.5	23500	22600	21500	20400	19300	18160
		--	DDA24T31000BM	10	27800	26750	25500	24250	23300	22150
		--	DDA34T31500BM	15	31300	30300	29100	28250	26600	25130
	36"	--	DDA36T30200CM	2.0	14000	12400	10600	8390	5530	--
		--	DDA36T30300CM	3.0	19400	17550	15600	13100	8980	6450
		--	DDA36T30500CM	5.0	23600	22050	19700	16850	11700	9220
		DDA36T10500B	DDA36T30500BM	5.0	16200	15200	14200	12800	12200	11050
		--	DDA36T30750CM	7.5	26100	23800	21600	18350	12900	11050
		DDA36T10750B	DDA36T30750BM	7.5	21500	20400	19400	18350	17100	15850
		--	DDA36T31000BM	10.0	29700	28550	27300	26150	24900	23700
		--	DDA36T31500BM	15.0	34320	32960	31970	30680	29280	28030
	42"	--	DDA42T30200DM	2.0	19200	16300	12400	6720	--	--
		--	DDA42T30300DM	3.0	23210	20230	16280	8980	3940	--
		--	DDA42T30500DM	5.0	28900	25600	20800	11100	6290	--
		--	DDA42T30500CM	5.0	25500	23550	21100	18300	14200	10100
		--	DDA42T30750CM	7.5	30690	28750	26190	23350	19410	12780
		--	DDA42T31000CM	10.0	38300	35700	33100	29450	23000	15400
		--	DDA42T31000BM	10.0	26700	25200	23750	22380	21100	19570
		--	DDA42T31500BM	15.0	39100	38080	36700	34640	33500	32040
		--	DDA42T32000BM	20.0	43300	42280	40860	39170	37600	36140
	48"	--	DDA48T30500DM	5.0	29820	26940	23790	12790	12790	6740
		--	DDA48T30750DM	7.5	35700	32450	28600	16800	16800	8270
		--	DDA48T31000CM	10.0	37200	35300	33200	30800	27700	24000
		--	DDA48T31500CM	15.0	47300	45050	42300	36200	36200	33490
		--	DDA48T32000CM	20.0	53900	51450	48400	42300	42300	37120
