Triangle Engineering of Arkansas Model PFG (Single Speed)Direct Drive Heavy Duty Agricultural Wall Exhaust Fan CFM Range:10,740-18,800 (Sizes 36" thru 48")
Price:
$539.23
|
PFG Series Features : All galvanized construction for corrosion resistance in harsh atmosphere
Galvanized welded 1" x 2" wire guard on intake and exhaust
Assembled, ready to install
36", 42", or 48" blades
60 Hertz, totally enclosed air over (TEAO) motors with thermal protection
50 Hertz motors available on selected models
230V, 10 ft. Power cord with 3-prong molded plug
Bolt-together design for easy part replacement
Limited 3-year warranty
|
Printable Manual (336 Kb) |
Model Number
|
Blade Dia.
|
H.P.
|
Amps
|
Volts
|
RPM @
0" S.P.
|
.00" S.P.
|
.05" S.P.
|
.10" S.P.
|
|||
|
CFM
|
CFM Watt
|
CFM
|
CFM Watt
|
CFM
|
CFM Watt
|
||||||
|
16" Housing - Direct Drive - Three-Wing Blade
|
|||||||||||
|
PFG 3613 D
|
36"
|
1/2
|
6.0/3.0
|
115/230/1
|
843
|
10,740
|
19.6
|
9,960
|
17.4
|
9,100
|
15.3
|
|
PFG 4213 D
|
42"
|
1/2
|
6.0/3.0
|
115/230/1
|
794
|
13,060
|
18.8
|
11,680
|
15.9
|
10,300
|
13.3
|
|
PFG 4815 D
|
48"
|
1
|
4.6
|
230/1
|
839
|
18,800
|
20.6
|
17,900
|
19.0
|
16,000
|
16.5
|
|
PFG 4815D-460
|
48"
|
1
|
5.2/2.6
|
5.2/2.6
|
839
|
18,800
|
20.6
|
17,900
|
19.0
|
16,000
|
16.5
|
*Note: 50 Hz and Explosion Proof Motors are Available on Select Models
