Canarm Ltd. brand Model P Wall Exhaust Fan (Variable Speed) Single Phase Direct Drive w/Motorized Damper CFM Range: 1,650 - 5,500 (Sizes 12" thru 24")
Model P Exhaust Fan
| - Fully Assembled. - Sturdily constructed direct drive, horizontal discharge fan. - Durable powder coat finish. - Heavy duty OSHA motor mount/guard is standard. - Totally enclosed air over motor with overload protection. - Complete with wall sleeve and motorized damper (sleeve is 9" deep.) |
| Leader Fan Number | Blade Dia. | H.P. | Volts | CFM @ Static Pressure |
Weight LBS. |
|||
| 0" | 0.1" | 0.125" | 0.250" | |||||
| Single Speed Speed Fan | ||||||||
| P12-1VS9M115 | 12" | 1/3 | 115/230 | 1,650 | 1,560 | 1,525 | 1,400 | 48 |
| P14-1VS9M115 | 14" | 1/3 | 115/230 | 2,170 | 2,030 | 1,950 | 1,900 | 52 |
| P16-1VS9M115 | 16" | 1/3 | 115/230 | 2,570 | 2,470 | 2,410 | 2,260 | 54 |
| P18-1VS9M115 | 18" | 1/3 | 115/230 | 3,150 | 3,000 | 2,900 | 2,575 | 64 |
| P20-1VS9M115 | 20" | 1/3 | 115/230 | 3,620 | 3,420 | 3,340 | 3,120 | 70 |
| P24-1VS9M115 | 24" | 1/3 | 115/230 | 5,500 | 5,400 | 5,310 | 5,100 | 78 |
This is a self-contained variable speed wall exhaust fan assembled complete with wall sleeve, OSHA intake guard and power open/spring closed actuator operated motorized intake shutter. Perfect for positive exhaust applications for Industrial, Commercial and Agricultural applications where a motorized shutter is required.
