TPI brand Shutter Mount 120V Direct Drive Two and Three Speed Wall Exhaust Fans with Pull Chain (10" thru 30")

Now accepting PayPal

1-317-531-1638

Installs on inside wall

Eliminates need for external framing & shutter

MOTOR..............120V, 1-phase totally enclosed permanently lubricated - UL listed.
1/12 HP Motor...is 3-speed sleeve bearing shaded pole type.
1/8 HP Motor......is 3-speed sleeve bearing permanent split capacitor.
1/4 HP Motor.....is 2-speed ball bearing permanent split capacitor.
SWITCH.............Pull Chain
CORD.................NONE - Junction box provided for direct wiring.
GUARDS.............Steel spiral wire.
BLADE................Aluminum.

Printable Manual (365.0 kb)

SIZE	MODEL NUMBER	MOTOR HP	CFM			AMPS	VOLTS	SHIPPING WEIGHT
SIZE	MODEL NUMBER	MOTOR HP	HIGH	MED	LOW	AMPS	VOLTS	SHIPPING WEIGHT
10"	CE 10-DS	1/12	680	540	460	1.0	120	11
12"	CE 12-DS	1/12	825	710	560	1.1	120	16
14"	CE 14-DS	1/8	1520	1400	1250	2.0	120	17
16"	CE 16-DS	1/8	2100	1900	1700	2.1	120	18
18"	CE 18-DS	1/8	2300	2100	1850	2.2	120	25
20"	CE 20-DS	1/4	2925	-	2380	2.3	120	34
24"	CE 24-DS	1/4	3400	-	2770	2.5	120	47
30"	CE 30-DS	1/4	3950	-	3080	2.7	120	54

Model #CE 10-DS (10" Size, 1/12 HP, 120V, 3-Speed, 680/540/460 CFM)

SKU: CE 10-DS

Weight: 11.00

Price: $265.50

Model #CE 12-DS (12" Size, 1/12 HP, 120V, 3-Speed, 825/710/560 CFM)

SKU: CE 12-DS

Weight: 16.00

Price: $301.39

Model #CE 14-DS (14" Size, 1/8 HP, 120V, 3-Speed, 1520/1400/1250 CFM)

SKU: CE 14-DS

Weight: 17.00

Price: $380.88

Model #CE 16-DS (16" Size, 1/8 HP, 120V, 3-Speed, 2100/1900/1700 CFM)

SKU: CE 16-DS

Weight: 18.00

Price: $395.22

Model #CE 18-DS (18" Size, 1/8 HP, 120V, 3-Speed, 2300/2100/1850 CFM)

SKU: CE 18-DS

Weight: 25.00

Price: $429.71

Model #CE 20-DS (20" Size, 1/4 HP, 120V, 2-Speed, 2925/2380 CFM)

SKU: CE 20-DS

Weight: 34.00

Price: $509.63

Model #CE 24-DS (24" Size, 1/4 HP, 120V, 2-Speed, 3400/2770 CFM)

SKU: CE 24-DS

Weight: 47.00

Price: $570.77

Model #CE 30-DS (30" Size, 1/4 HP, 120V, 2-Speed, 3950/3080 CFM)

SKU: CE 30-DS

Weight: 54.00

Price: $729.30
