16 Ft. Altra Air Sailfin (HVLS) High Volume Low Speed Industrial Ceiling Fans (1-1/2 Hp, 208/230V, 1 Ph, 127,033 CFM, Var. Speed)
16' Printable Brochure (819 Kb)Sailfin Installation Guide (4,569 Kb)
Sailfin Electrical Installation Guide (3,499Kb)
Sailfin Control Options (978 Kb)
Sailfin General Brochure (2,222 Kb)
Sailfin Warranty Brochure (53 Kb)
Price:
$3,743.10
Ships in 7-9 Business Days
Altra-Air Application
Altra-air fans blanket a very large area with constantly moving air to create an expansive comfort zone. As a result, in hot humid weather these big ceiling fans will create an evaporative cooling effect of two to four degrees Celsius throughout. During the heating season the Altra-Air fan technology can de-stratify uneven temperatures that can be in excess of 15 degrees Celsius from floor to ceiling. This results in significant energy savings since the heating system cycles less frequently. Hot and cold spots are also eliminated.
Altra-Air Advantage
- Five bladed High Volume Low Speed Fan
- Increased blade pitch means more air.
- Inexpensive to operate.
- Very low decibel level.
- Proven to save energy year-round.
- Simply the best fan on the market.
Technical Specifications
- Fans is 16' in diameter. Number of Blades = 5. Shipping Weight = 440lbs
- Capable of moving 127,033 CFM, 80 RPM, 62.7 dBA (Sound)
- Operates on 1-1/2 Hp, 208V or 230V, 1 Phase
- Variable frequency drive provides soft start & full variable speed operation.
- Creates a non-disruptive air flow and is reversible
