Canarm Ltd. brand Model ALX-DD Down Blast Direct Drive Spun Aluminum Centrifugal Roof Exhaust Fan or Wall Mount Exhaust Fan Single Phase Gen. Application CFM Range: 500 -4,400
Price:
$401.56
ALX-DD Series - Down Blast Direct Drive Spun Aluminum Roof Exhauster
Ideal for exhausting air from factories, offices, warehouses or commercial buildings. The ALX series spun aluminum exhaust fan can be used as either a roof top or wall mount exhaust fan.
FEATURES
- Spun aluminum housing will not rust, chip or peel.
- Aluminum backward inclined wheel is non-overloading.
- Available with PSC or EC Motors.
- Variable speed PSC motors available on ALX 090/105/120/135
- All motors are 1 Phase 120/240V operation can be operated at 50 or 60 Hz.
- All units can be wall mounted.
- Quick release latches for easy motor access on ALX135-ALX165.
EC MOTORS ONLY
- EC motors offer true variable speed operation and up to 70% energy savings over PSC motors.
- On-board speed adjustment allows simple setup and balancing with LED display.
- Can be controlled remotely up to 50' using a remote mount potentiometer or 0-10V.
|
TYPICAL MAXIMUM CFM @ STATIC PRESSURE |
|||||
|
Model |
HP |
Variable Speed |
0”SP |
1/4”SP |
1/2”SP |
|
ALX090-DD008V |
1/12 |
Y |
500 |
425 |
300 |
|
ALX105-DD013V |
1/8 |
Y* |
950 |
875 |
760 |
|
ALX105-DD033EC |
1/3 |
Y |
1100 |
1003 |
877 |
|
ALX120-DD033V |
1/3 |
Y* |
1300 |
1200 |
1000 |
|
ALX120-DD033EC |
1/3 |
Y |
1544 |
1406 |
1279 |
|
ALX120-DD050EC |
1/2 |
Y |
1610 |
1477 |
1357 |
|
ALX135-DD075V |
3/4 |
N |
1950 |
1900 |
1800 |
|
ALX135-DD033EC |
1/3 |
Y |
1578 |
1469 |
1341 |
|
ALX135-DD050EC |
1/2 |
Y |
1843 |
1747 |
1645 |
|
ALX135-DD075EC |
3/4 |
Y |
2150 |
2075 |
2000 |
|
ALX150-DD100S |
1 |
N |
2600 |
2500 |
2400 |
|
ALX150-DD033EC |
1/3 |
Y |
1806 |
1649 |
1425 |
|
ALX150-DD050EC |
1/2 |
Y |
2133 |
2003 |
1842 |
|
ALX150-DD075EC |
3/4 |
Y |
2424 |
2312 |
2182 |
|
ALX150-DD100EC |
1 |
Y |
2625 |
2575 |
2450 |
|
ALX165-DD150S |
1 1/2 |
N |
3500 |
3400 |
3200 |
|
ALX165-DD033EC |
1/3 |
Y |
2264 |
2034 |
1787 |
|
ALX165-DD050EC |
1/2 |
Y |
2529 |
2328 |
2115 |
|
ALX165-DD075EC |
3/4 |
Y |
2909 |
2731 |
2546 |
|
ALX165-DD100EC |
1 |
Y |
3250 |
3100 |
3000 |
|
ALX180-DD100EC |
1 |
Y |
3800 |
3625 |
3325 |
|
ALX210-DD100EC |
1 |
Y |
4400 |
4000 |
3600 |
EC Motors can be controlled using the built-in potentiometer on motor or by using a 0 to 10V controller.
 |
 |
