Model #CHD10-1036A 3-Speed Commercial High Performance Air Curtain (3Ft.) or 36in. Wide 1/2 Hp, Motor up to 10Ft. Door Height 1 or 3 Phase

The Commercial Series High Performance Air Curtain is designed for 36” wide doorways of up to 10ft in height for environmental control or 8ft for insect control. Ideal for service doors, ghost kitchens, conveyor systems, shipping doorways, as an alternative to vestibules, main entrances, and other high traffic areas. This air curtain is UL certified, AMCA certified performance, complies with ASHRAE 90.1 requirements, and is made in the USA with a limited 5-year warranty. It creates a steady stream of air over your doorway, keeping outside air separate from your AC or heated air. Features heated air for additional comfort on cold days, an aluminum housing in white and is designed for indoor mounting only.

• EPH Listed per NSF 37
• 14.09" High x 14.53" Deep
• 1/2 Hp Three Speed Motor
• White or Black Powder Coated Exterior
• Wall & Top Mounting
• Five Years Parts Warranty
• No Assembly Required
• Wall Plate Included

• Optional Filter (washable)

Cabinet Dimensions = 39" Wide (36" Nozzle Width) x 14.09" High x 14.53" Deep

 Construction = White or Black Aluminum Exterior Cover

 Voltage = 120/208/240V

 Hertz = 60

 Amps = 6.5/3.5/3.5

 Horsepower = 1 Motor @ 1/2 Hp

 Speeds = 3

 CFM High = 1,804

 Decibels (dBA) = 66 @ 10 Ft.

 Warranty = 5 Year Limited

 Drive = Direct

 Weight = 50lbs
