Soler & Palau USA brand Model SDB Downblast Belt Drive Centrifugal Roof Exhaust Fan

Options:

Price: $1,187.33

SKU: SDB18PH1S

Got Questions or Need a Quote? We're Ready to Help!

Description
Reviews

MODEL SDB
DOWNBLAST BELT DRIVE CENTRIFUGAL ROOF EXHAUSTER

Application
Soler & Palau USA brand down blast belt drive roof exhaust fans are designed to handle relatively clean air streams for applications ranging from commercial, industrial and institutional environments such as manufacturing facilities and assembly plants, office buildings, schools, hospitals, restaurants, athletic facilities and much more.

The backward inclined centrifugal blower wheel is nonoverloading and is capable of maintaining its performance levels at higher static pressure applications making it suitable for both ducted and non-ducted exhaust applications. Since the fan is roof mounted, you have the option of locating the exhaust fan in close proximity to the area where need most allowing shorter duct runs and more efficient operation.

Since this is a belt driven centrifugal roof exhaust fan, it is possible to adjust the performance as needed by changing the pitch of the motor sheave. This allows easy you balance the total ventilation system when necessary. Belt driven centrifugal roof exhaust fans allow you to operate at a lower operating rpm resulting in a quiet smooth operation.

Product Bulletin and Detailed Performance Chart (470 kB)
Accessories (233 kB)
Installation and Operation Manual (640 kB)

CONSTRUCTION

Housing

Heavy-gauge aluminum for extra strength with prepunched mounting holes.

Neoprene isolators for reduction of vibration and sound.

Cover easily removed for quick access to motor compartment.

Water tight conduit tube for easy electrical connection.

Aluminum bird screen and disconnect are standard.

Lifting lugs for easy and safe placement on roof.

Stainless steel exterior fasteners.

Centrifugal Wheel

All aluminum backward inclined wheel.

Nonoverloading for safe operation in ducted systems.

Dynamically balanced for smooth operation

Drives

Sized for minimum 150% of drive horsepower.

Machined cast iron adjustable motor pulleys

Adjustable base for belt tensioning.

Nonstatic oil resistant v-belts.

Motors

Single speed open drip-proof are standard.

All motors are rated for continuous duty.

182T and larger motors shipped unmounted for field installation.

Disconnect switch standard with single speed drip-proof motors.

Bearings

Heavy-duty ball bearing type.

Prelubricated and permanently sealed.

Note: Curb adapters and explosion proof motors are available. Please call customer service @ 317-531-1638 for more details.

Models SDB18PH1S, SDB18PH3S, SDB18QH1S, SDBQH3S, SDB18RH1S, SDB18RH3S, SDB18SH1S, SDB18SH3S, SDB18TH1S, SDB18TH3S, SDB18VH1S, SDB18VH3S, SDB20PH1SSDB20PH3S, SDB20HQ1S, SDB20QH3S, SDB20RH1S, SDB20RH3S, SDB20SH1S, SDB20SH3S, SDB20TH1S, SDB20TH3S, SDB20VH1S, SDB20VH3S, SDB22PH1S, SDB22PH3S, SDB22QH1S, SDB22QH3S, SDB22RH1S, SDB22RH3S, SDB22SH1S, SDB22SH3S, SDB22TH1S, SDB22TH3S, SDB22VH1S, SDB22VH3S, SDB24PH1S, SDB24PH3S, SDB24QH1S, SDB24QH3S, SDB24RH1S, SDB24RH3S, SDB24SH3S, SDB24TH3S, SDB24VH3S
